The L1-40 laser distance sensor module is a compact TTL-output ranging solution designed for embedded control and industrial automation tasks. Based on visible 650 nm laser technology, it delivers stable distance measurement from 0.05 m to 40 m with millimeter-level resolution.
Operating from a 5 V DC supply, the module achieves low power consumption while supporting sampling rates up to 20 Hz, making it suitable for continuous real-time monitoring. The TTL UART interface allows direct integration with MCUs, embedded controllers, and industrial computers without additional signal conversion.
With an absolute accuracy of ±(1 mm + D×5‰) and repeatability of ±1 mm, the L1-40 performs reliably in dimensional measurement, positioning feedback, and object distance detection. The optical system uses a Class 1 eye-safe laser with a small spot size, ensuring safe operation and precise targeting.
Designed for indoor and controlled industrial environments, the module operates across a temperature range of −10 °C to +50 °C. Its compact PCB form factor enables easy mechanical integration into OEM devices, automation equipment, and custom sensor assemblies.
Typical applications include industrial automation, AGV/AMR distance sensing, equipment positioning, smart manufacturing systems, and embedded measurement solutions.
Applications
-
Embedded & OEM Integration
- Embedded control boards
- MCU / SoC based systems
- Industrial electronic modules
Automation & Robotics
- AGV / AMR distance feedback
- Position reference and motion control
- Equipment stroke and clearance monitoring
Industrial Electronics Environment
- Industrial cabinets and control boxes
- Systems requiring EMC-compliant components
- Integration inside customer-designed enclosures
Application Notes
- Designed primarily for embedded and indoor applications.
- For long-range measurement (especially 80 m), reflective targets improve accuracy and stability.
- Performance may be affected under strong outdoor sunlight.
- External housing or protection is recommended for harsh environments.
| Dimensions |  |
|---|
| Measurement Range | 0.03–40m |
|---|---|
| Output Interface | TTL UART |
| Accuracy | ±1mm |
| Sampling Rate | 10Hz(10 times per second), 20Hz(20 times per second), default 20HZ |
| Power Supply | DC 5 V |
| Repeatability | ±1mm |
| Dismensions | 54.35 × 36.61 × 14.3 mm |
| Operating Temperature: | –10 °C to +50 °C |
| Operating Humidity | ≤85 % RH |
| Laser Wavelength | 650 nm |
| Communication Protocol | Modbus_RTU/ ASCII/Custom Hex |
| Power Consumption | 0.6W@20Hz, , standby <0.2W |
| System Startup Time | 600ms |
| Serial Port Format | Baud rate : 38400 Data bits : 8 Stop bits : 1 Verification : none Flow Control : none |
| Net Weight | 15.8 g |
| Gross Weight | 17.1g |
| Resolution | 1 mm |
| Applications | AGV / AMR Navigation, Deformation Monitoring, Displacement Measurement, Industrial Automation, Level Monitoring, Material Level Measurement, Smart Construction |
