The L1 Series TTL Laser Distance Sensors use phase-shift laser ranging, a proven measurement principle for short- and medium-range applications requiring high accuracy and fast response. By continuously modulating the emitted laser beam and analyzing the phase difference of the reflected signal, the sensor calculates distance with millimeter-level precision.

Unlike enclosed industrial sensors, the L1 series is designed as a compact module, making it ideal for embedded systems, OEM products, and custom housings. The TTL UART interface enables direct connection to microcontrollers, single-board computers, and embedded controllers, minimizing system complexity.

The L1-40 is optimized for short-range precision tasks, while the L1-80 supports extended measurement distances when reflective targets are used. Both models provide stable performance, low power consumption, and flexible communication settings for system integration.

Specifications

Model-Specific Parameters

Applications

• Embedded distance measurement systems
• Robotics and autonomous equipment
• Smart devices and intelligent terminals
• OEM laser ranging modules
• Position feedback and displacement control
• Small target detection and monitoring
• Custom laser measurement solutions

Application Notes

• Designed primarily for embedded and indoor applications.
• For long-range measurement (especially 80 m), reflective targets improve accuracy and stability.
• Performance may be affected under strong outdoor sunlight.
• External housing or protection is recommended for harsh environments.
