The L1S-40 Potting IP67 Laser Distance Sensor applies phase-shift laser measurement, offering precise and repeatable distance data for industrial control and monitoring. The fully potting-filled structure significantly enhances resistance to vibration, impact, moisture, and dust.
With an IP67 rating, the sensor can withstand water exposure and harsh industrial conditions where standard sensors are unsuitable. The TTL UART interface enables direct integration with microcontrollers and embedded systems, making the L1S-40 IP67 ideal for demanding OEM and automation applications.
Specifications
| Item | Specification |
|---|---|
| Measurement Principle | Phase-Shift Laser Distance Measurement |
| Measuring Range | 0.05–40 m |
| Resolution | 1 mm |
| Accuracy | ±(1 mm + D × 5‰), typical ±1 mm |
| Repeatability | ±1 mm |
| Sampling Rate | 10 Hz / 20 Hz (default 20 Hz) |
| Laser Wavelength | 650 nm |
| Optical Power | < 1 mW |
| Laser Type | Visible red dot laser |
| Spot Size | < 5 mm @ 10 m |
| Laser Lifetime | Approx. 20,000 hours |
| Power Supply | DC 5 V |
| Power Consumption | 0.6 W @ 20 Hz; standby < 0.2 W |
| System Startup Time | 600 ms |
| Communication Interface | TTL UART |
| Baud Rate | 9600 / 19200 / 38400 / 115200 (default 38400) |
| Serial Format | 8 data bits, 1 stop bit, no parity |
| Communication Protocols | Modbus RTU / ASCII / Custom Hex |
| Reference Point | Front reference |
| Operating Temperature | –10 °C to +50 °C |
| Operating Humidity | ≤ RH 85% |
| Protection Level | IP67 |
| Structure | Fully potting-filled |
| Cable Type | Aviation cable |
Applications
- Harsh industrial environments
- Equipment exposed to moisture or wash-down
- Outdoor or semi-outdoor installations (with protection considerations)
- Robotics and mobile equipment
- Embedded industrial systems
- OEM laser ranging solutions
